MSI Gaming GL65 10SDR-056CN Leopard RAM upgrade specifications

MSI GL65 10SDR-056CN Leopard MSI GL65 10SDR-056CN Leopard MSI GL65 10SDR-056CN Leopard MSI GL65 10SDR-056CN Leopard MSI GL65 10SDR-056CN Leopard

MSI GL65 10SDR-056CN Leopard gaming laptop supports DDR4-SDRAM memory upgrades with 2x SO-DIMM slots. Maximum RAM capacity reaches 64 GB total. Compatible memory operates at 2666 MHz frequency using SO-DIMM form factor. Upgrade specifications enable expansion from factory configuration to enhanced memory capacity for improved multitasking performance on MSI GL series gaming machine.

Memory Upgrade Specifications

SpecificationValue
Memory slots2x SO-DIMM
Form factorSO-DIMM
Memory typeDDR4-SDRAM
Frequency2666 MHz
Maximum RAM64 GB
Voltage1.2V
Number of pins260-pin
InterfacePC4
PC Speed RatingPC4-2666 (PC4-21328)
Bandwidth21.3 GB/s
Laptop Release date15 June 2020

Additional Notes

  • The dual channel architecture implies that installing modules in pairs is necessary to achieve the full theoretical memory bandwidth.
  • The MSI GL65 10SDR-056CN Leopard utilizes a standard 260 pin physical interface which limits compatibility to mobile form factor modules rather than desktop variants.
  • Upgrading to modules with speeds higher than 2666 MHz will result in the system downclocking the memory to match the hardcoded controller limit.
  • Populating both available slots with 32 GB modules is the only method to reach the maximum supported capacity due to the lack of additional banks.
  • Mixing modules of different densities or timings may trigger a fallback to single channel mode or cause instability in the system BIOS.
  • Accessing the SO-DIMM slots requires the removal of the entire base panel which involves breaking a factory seal sticker in certain regions.
  • The internal layout dictates that memory chips must be unbuffered and non-ECC to pass the power on self test.
