MSI Gaming GL76 12UGK-092UK Pulse RAM upgrade specifications
The MSI GL76 12UGK-092UK Pulse gaming laptop features DDR4-SDRAM memory configuration with 2x SO-DIMM slots supporting maximum capacity of 64 GB RAM. The upgrade specifications indicate compatible memory operating at 3200 MHz frequency. Each SO-DIMM slot accommodates individual memory modules, enabling users to expand the GL series laptop's total memory capacity. The GL76 Pulse model supports DDR4 technology with specifications designed for gaming performance requirements. Maximum RAM upgrade capacity reaches 64 GB across the available memory slots.
Memory Upgrade Specifications
| Specification | Value |
|---|---|
| Memory slots | 2x SO-DIMM |
| Form factor | SO-DIMM |
| Memory type | DDR4-SDRAM |
| Frequency | 3200 MHz |
| Maximum RAM | 64 GB |
| Voltage | 1.2V |
| Number of pins | 260-pin |
| Interface | PC4 |
| PC Speed Rating | PC4-3200 (PC4-25600) |
| Bandwidth | 25.6 GB/s |
| Laptop Release date | 22 December 2021 |
Additional Notes
- The MSI GL76 12UGK-092UK Pulse contains 2 SO-DIMM slots that operate as a matched pair; installing a single module will force single-channel operation, reducing memory bandwidth by approximately 50% and degrading gaming frame rates and application responsiveness.
- DDR4-3200 modules are backward compatible with faster DDR4 standards but will operate at 3200 MHz maximum; purchasing DDR5 memory is incompatible with this platform and represents wasted expenditure.
- The 64 GB ceiling assumes 2x 32 GB SO-DIMM modules; retail availability of 32 GB SO-DIMMs in DDR4-3200 specification is limited, and such modules typically command premium pricing compared to 16 GB alternatives.
- SO-DIMM form factor requires removal of the keyboard or access panel to reach memory slots; unlike desktop systems, RAM installation carries risk of damaging ribbon cables and integrated circuitry if performed without proper disassembly procedures.
- Memory frequency of 3200 MHz is standard for 12th-generation Intel processors in this chassis; timing latencies (CAS) of 16 or lower will maximize compatibility with the JEDEC specification but do not guarantee operational stability without BIOS validation.
- Upgrading beyond 32 GB total capacity provides marginal performance benefit for gaming workloads; the performance ceiling is typically reached at 16 GB configuration, with additional capacity benefiting content creation and virtualization applications only.
