MSI Gaming GP72 7REX-629IT Leopard Pro RAM upgrade specifications
The MSI GP72 7REX-629IT Leopard Pro gaming laptop features DDR4-SDRAM memory upgrade specifications. The system contains two SO-DIMM memory slots supporting a maximum capacity of 32 GB total RAM. Compatible memory modules operate at 2400 MHz frequency. Upgrade options allow for expansion by replacing or adding DDR4 SO-DIMM modules. The specifications indicate memory slots support standard laptop memory form factors, enabling users to enhance system RAM capacity for improved multitasking and gaming performance on the MSI Gaming GP series platform.
Memory Upgrade Specifications
| Specification | Value |
|---|---|
| Memory slots | 2x SO-DIMM |
| Form factor | SO-DIMM |
| Memory type | DDR4-SDRAM |
| Frequency | 2400 MHz |
| Maximum RAM | 32 GB |
| Voltage | 1.2V |
| Number of pins | 260-pin |
| Interface | PC4 |
| PC Speed Rating | PC4-2400 (PC4-19200) |
| Bandwidth | 19.2 GB/s |
| Laptop Release date | 04 January 2018 |
Additional Notes
- Dual-channel memory architecture requires matching modules in both slots to maximize memory controller bandwidth and enhance gaming frame rate stability.
- The MSI GP72 7REX-629IT Leopard Pro supports 16 GB modules per slot to reach the maximum capacity limit of the HM175 chipset.
- Installation of memory modules with frequencies exceeding 2400 MHz results in automatic downclocking to the hardware-defined motherbord limit.
- Physical access to the SO-DIMM slots requires the removal of the entire bottom chassis panel which involves breaking the factory seal sticker.
- Integrating 1.2V DDR4 modules is necessary to ensure compatibility with the power delivery system of the motherboard.
- Mixing modules of different capacities or timings can force the system into single-channel mode or lead to boot failures due to SPD mismatch.
- The 2 slot configuration prevents further expansion once the 32 GB threshold is met as there are no additional headers on the PCB.
