MSI Gaming GP68HX 13VH-096XES RAM upgrade specifications
MSI GP68HX 13VH-096XES gaming laptop memory upgrade specifications feature DDR5-SDRAM technology with 2x SO-DIMM slots supporting maximum capacity of 64 GB RAM. Compatible memory modules operate at 5600 MHz frequency with SO-DIMM form factor. Upgrade specifications indicate dual-channel memory configuration enabling enhanced multitasking and application performance for gaming series systems.
Memory Upgrade Specifications
| Specification | Value |
|---|---|
| Memory slots | 2x SO-DIMM |
| Form factor | SO-DIMM |
| Memory type | DDR5-SDRAM |
| Frequency | 5600 MHz |
| Maximum RAM | 64 GB |
| Voltage | 1.1V |
| Number of pins | 262-pin |
| Interface | PC5 |
| PC Speed Rating | PC5-5600 (PC5-44800) |
| Bandwidth | 44.8 GB/s |
| Laptop Release date | 22 July 2023 |
Additional Notes
- The dual slot configuration allows for a symmetrical dual channel architecture which doubles theoretical memory bandwidth compared to single channel setups.
- The MSI GP68HX 13VH-096XES architecture necessitates the removal of the bottom chassis panel for component access which typically requires breaking a factory seal.
- Installation of high capacity modules will likely result in a longer initial boot cycle during the first power on due to the extended training period of the memory controller.
- Operating at the specified 5600 MHz frequency requires the processor and BIOS to support specific XMP or JEDEC profiles to avoid downclocking to base speeds.
- Mixing modules of different densities or ranks within the two SO-DIMM slots can lead to system instability or a fallback to lower clock frequencies.
- Thermal management constraints within the laptop chassis may limit the use of modules with thick integrated heat spreaders due to vertical clearance limits.
- The 64 GB limit indicates a firmware or hardware cap that prevents the utilization of 48 GB or 64 GB individual modules released after the initial product launch.
