MSI Gaming GS63 7RD-223 Stealth RAM upgrade specifications

MSI GS63 7RD-223 Stealth MSI GS63 7RD-223 Stealth MSI GS63 7RD-223 Stealth MSI GS63 7RD-223 Stealth MSI GS63 7RD-223 Stealth

MSI GS63 7RD-223 Stealth laptop RAM upgrade specifications include DDR4-SDRAM memory compatible with 2x SO-DIMM slots. Maximum capacity reaches 32 GB total memory, supporting 2400 MHz frequency. The Gaming series model accepts standard SO-DIMM form factor modules. Upgrade options enable users to expand existing memory configuration up to specified maximum specifications.

Memory Upgrade Specifications

SpecificationValue
Memory slots2x SO-DIMM
Form factorSO-DIMM
Memory typeDDR4-SDRAM
Frequency2400 MHz
Maximum RAM32 GB
Voltage1.2V
Number of pins260-pin
InterfacePC4
PC Speed RatingPC4-2400 (PC4-19200)
Bandwidth19.2 GB/s
Laptop Release date25 February 2018

Additional Notes

  • The internal layout of the MSI GS63 7RD-223 Stealth requires the removal of the entire motherboard to access the memory slots because they are located on the underside of the PCB.
  • Dual channel mode functionality relies on installing matching modules in both slots to double the available communication bandwidth between the processor and the memory controller.
  • Installing modules with speeds exceeding 2400 MHz results in automatic downclocking to match the native motherboard chipset limitations.
  • Memory expansion to the 32 GB limit necessitates 2 16 GB modules as the hardware architecture does not support single 32 GB sticks.
  • Non ECC unbuffered memory modules are required for system stability as registered or buffered server memory prevents the device from posting.
  • The use of 1.2V low voltage modules is necessary to maintain thermal efficiency within the thin chassis design and prevents overvoltage issues.
  • Factory seal breakage during the motherboard inversion process potentially voids standard warranty terms depending on regional consumer protection laws.
