MSI Gaming GS75 10SGS-071IT Stealth RAM upgrade specifications
MSI GS75 10SGS-071IT Stealth gaming laptop features DDR4-SDRAM memory upgrade specifications. The system includes two SO-DIMM slots supporting maximum RAM capacity of 64 GB. Compatible memory modules operate at 2666 MHz frequency. This Gaming Series configuration allows for memory expansion upgrades to enhance system performance. The SO-DIMM form factor specifications define compatible RAM module requirements for this particular MSI GS75 model variant.
Memory Upgrade Specifications
| Specification | Value |
|---|---|
| Memory slots | 2x SO-DIMM |
| Form factor | SO-DIMM |
| Memory type | DDR4-SDRAM |
| Frequency | 2666 MHz |
| Maximum RAM | 64 GB |
| Voltage | 1.2V |
| Number of pins | 260-pin |
| Interface | PC4 |
| PC Speed Rating | PC4-2666 (PC4-21328) |
| Bandwidth | 21.3 GB/s |
| Laptop Release date | 05 May 2020 |
Additional Notes
- The motherboard architecture of the MSI GS75 10SGS-071IT Stealth utilizes a flipped design where the memory slots face the keyboard side rather than the bottom panel.
- Accessing both SO-DIMM slots requires a full removal of the mainboard from the chassis which voids standard factory seals in specific regions.
- Dual channel memory configuration is mandatory to prevent bandwidth starvation for the integrated graphics and high refresh rate display output.
- Installing modules with speeds exceeding 2666 MHz results in automatic downclocking to match the hardware controller limitations of the 10th generation chipset.
- Thermal management constraints within the slim chassis limit the use of memory modules equipped with thick heat spreaders due to vertical clearance issues.
- Populating 64 GB of RAM necessitates the use of high density dual rank modules which increases electrical trace latency compared to single rank alternatives.
- Voltage requirements are fixed at 1.2V meaning high performance overclocked kits requiring 1.35V will likely fail to boot or remain unstable.
