MSI Gaming GT75 Titan 4K-247 RAM upgrade specifications
The MSI GT75 Titan 4K-247 Gaming series laptop features four SO-DIMM memory slots supporting DDR4-SDRAM specifications. Maximum RAM capacity reaches 128 GB total, with compatible memory operating at 2666 MHz frequency. Upgrade specifications allow installation of DDR4 SO-DIMM modules in all four available slots to achieve maximum memory configurations for enhanced multitasking and performance capabilities.
Memory Upgrade Specifications
| Specification | Value |
|---|---|
| Memory slots | 4x SO-DIMM |
| Form factor | SO-DIMM |
| Memory type | DDR4-SDRAM |
| Frequency | 2666 MHz |
| Maximum RAM | 128 GB |
| Voltage | 1.2V |
| Number of pins | 260-pin |
| Interface | PC4 |
| PC Speed Rating | PC4-2666 (PC4-21328) |
| Bandwidth | 21.3 GB/s |
| Laptop Release date | 29 March 2019 |
Additional Notes
- The presence of 4 physical SO-DIMM slots implies a dual-channel architecture where memory modules must be installed in matched pairs to maintain peak data transfer rates.
- High-capacity configurations reaching the 128 GB limit require the use of high-density 32 GB modules which may increase thermal output within the memory bank area.
- Upgrading the MSI GT75 Titan 4K-247 necessitates sourcing non-ECC unbuffered modules because the chipset does not support error-correcting code functions.
- Mixing modules with different rated latencies will force the system to default to the slowest common timing profile across all occupied slots.
- Physical access to all 4 slots often requires significant disassembly because secondary slots are typically located on the reverse side of the motherboard beneath the keyboard assembly.
- Installing memory modules with speeds exceeding 2666 MHz results in automatic down-clocking to the motherboard maximum frequency limit.
- Large memory footprints improve performance in virtual machine hosting and high-resolution video rendering by reducing the frequency of swap file operations on the storage drive.
