MSI Stealth 14 RAM upgrade specifications
The MSI Stealth 14 Studio laptop features DDR5-SDRAM memory upgrade specifications with 2x SO-DIMM slots supporting maximum capacity of 64 GB RAM. Compatible memory modules operate at 5200 MHz frequency utilizing SO-DIMM form factor. Specifications enable memory expansion for enhanced multitasking and application performance on MSI Stealth 14 Studio model.
Memory Upgrade Specifications
| Specification | Value |
|---|---|
| Memory slots | 2x SO-DIMM |
| Form factor | SO-DIMM |
| Memory type | DDR5-SDRAM |
| Frequency | 5200 MHz |
| Maximum RAM | 64 GB |
| Voltage | 1.1V |
| Number of pins | 262-pin |
| Interface | PC5 |
| PC Speed Rating | PC5-5200 (PC5-41600) |
| Bandwidth | 41.6 GB/s |
| Laptop Release date | 05 October 2023 |
Additional Notes
- The MSI Stealth 14 memory controller operates at 5200 MHz, creating a theoretical maximum bandwidth of 83.2 GB/s. Upgrading to slower DDR5 modules will reduce this bandwidth proportionally, potentially impacting performance in memory-intensive workflows such as video editing or large dataset processing.
- Both SO-DIMM slots occupy the same memory channel configuration. Populating both slots with matched capacity modules enables dual-channel operation, doubling effective bandwidth compared to single-module configurations. Mismatched capacities or speeds will force the system to operate at the lowest common specification across both channels.
- The 64 GB ceiling is determined by the 2-slot architecture and DDR5 SO-DIMM density limits. Single 32 GB modules represent the maximum capacity per slot; expansion beyond 64 GB requires hardware redesign and is not achievable through component replacement.
- SO-DIMM physical dimensions restrict module height to approximately 30.35 mm. Heatspreader-equipped DDR5 modules with active cooling elements may exceed passive clearance within the chassis, requiring verification against the system's memory compartment depth before purchase.
- DDR5-SDRAM modules certified for 5200 MHz operation may include Intel XMP 3.0 or AMD EXPO profiles. Enabling these profiles in BIOS may void certain warranty provisions depending on MSI's terms. Manual frequency adjustment without profile engagement typically remains warranty-safe.
- The 2-slot limitation creates no upgrade path redundancy. Replacing both existing modules is required to increase total capacity; the system cannot retain functional memory while transitioning to larger modules, necessitating simultaneous removal and installation during upgrades.
