ASUS ProArt StudioBook W700G2T-AV002R RAM upgrade specifications
ASUS ProArt StudioBook Pro 17 W700G2T-AV002R features two SO-DIMM slots supporting DDR4-SDRAM memory upgrades. Maximum RAM capacity reaches 64 GB total. Compatible memory operates at 2666 MHz frequency. Upgrade specifications enable expansion beyond original configurations through standard SO-DIMM form factor modules. Dual memory slots provide flexibility for RAM capacity modifications in this professional workstation model.
Memory Upgrade Specifications
| Specification | Value |
|---|---|
| Memory slots | 2x SO-DIMM |
| Form factor | SO-DIMM |
| Memory type | DDR4-SDRAM |
| Frequency | 2666 MHz |
| Maximum RAM | 64 GB |
| Voltage | 1.2V |
| Number of pins | 260-pin |
| Interface | PC4 |
| PC Speed Rating | PC4-2666 (PC4-21328) |
| Bandwidth | 21.3 GB/s |
| Laptop Release date | 13 December 2019 |
Additional Notes
- The presence of 2 SO-DIMM slots implies that reaching the maximum 64 GB capacity requires the installation of 2 32 GB modules in a dual-channel configuration.
- Hardware architectural limits on the ASUS ProArt StudioBook W700G2T-AV002R motherboard prevent the utilization of high-speed 3200 MHz modules at their native rating, downclocking them to 2666 MHz.
- Upgrading memory requires the removal of the entire bottom chassis panel, which may involve navigating internal hidden clips and fragile ribbon cables for internal battery safety.
- Dual-channel memory parity is only achieved when both slots contain modules of identical density and rank, otherwise the system reverts to single-channel bandwidth performance.
- The 2666 MHz frequency ceiling dictates that low-latency CL19 or CL16 modules provide the only viable path for reducing memory bottlenecks within this specific chipset environment.
- Physical space within the 2 slots restricts the use of memory modules with integrated thick heat spreaders due to tight clearance between the PCB and the chassis cover.
- System stability for professional rendering tasks relies on using non-ECC unbuffered modules as the platform does not support Error Correction Code functionality for data integrity.
