ASUS ROG G513IE-HN002T RAM upgrade specifications

The ASUS ROG Strix G15 G513IE-HN002T gaming laptop features DDR4-SDRAM memory upgradeable through two SO-DIMM slots. Maximum RAM capacity reaches 32 GB total, operating at 3200 MHz frequency. Compatible memory modules utilize the SO-DIMM form factor standard for laptop upgrades. Specifications support DDR4 memory technology for enhanced multitasking and gaming performance on the Strix G15 series platform.

Additional Notes

• Dual channel mode functionality requires installing identical modules in both slots to maximize memory bandwidth for the Ryzen processor in this ASUS ROG G513IE-HN002T.
• The absence of soldered memory on the motherboard allows for the total replacement of factory modules if higher capacity or lower latency timing is required.
• Upgrading to the maximum 32 GB capacity necessitates 2 matching 16 GB modules because the system architecture does not support 32 GB single stick configurations.
• Latencies higher than CL22 at 3200 MHz will result in a performance bottleneck for CPU bound gaming tasks due to increased communication cycles between the processor and DRAM.
• Physical access to the SO-DIMM slots requires the removal of the bottom chassis panel which involves a pop open screw to prevent plastic clip damage during maintenance.
• Mixing modules with different rated speeds will force the memory controller to downclock all RAM to the lowest common frequency detected.
• The use of 1.2V DDR4 modules is mandatory as the motherboard lacks the voltage regulation hardware for high voltage overclocking kits.
• Standard height SO-DIMM modules must be utilized to ensure the internal copper heat shields and chassis clearance remain within factory tolerances.
