ASUS ROG G713IE-HX011W-BE RAM upgrade specifications
The ASUS ROG Strix G17 G713IE-HX011W-BE features DDR4-SDRAM memory upgrade capacity. The laptop contains two SO-DIMM memory slots for RAM expansion. Maximum supported memory capacity reaches 32 GB total. Compatible upgrades utilize DDR4 specifications operating at 3200 MHz frequency. SO-DIMM form factor memory modules are required for upgrading the memory configuration on this gaming laptop model.
Memory Upgrade Specifications
| Specification | Value |
|---|---|
| Memory slots | 2x SO-DIMM |
| Form factor | SO-DIMM |
| Memory type | DDR4-SDRAM |
| Frequency | 3200 MHz |
| Maximum RAM | 32 GB |
| Voltage | 1.2V |
| Number of pins | 260-pin |
| Interface | PC4 |
| PC Speed Rating | PC4-3200 (PC4-25600) |
| Bandwidth | 25.6 GB/s |
| Laptop Release date | 21 October 2021 |
Additional Notes
- Dual channel mode requires identical module capacities across both slots to maximize memory bandwidth for the AMD Ryzen processor architecture found in the ASUS ROG Strix G15 G713IE-HX011W-BE.
- The 32 GB ceiling necessitates replacing existing 4 GB or 8 GB modules because the motherboard lacks additional vacant slots for expansion.
- Utilizing modules with higher rated frequencies than 3200 MHz results in downclocking to the system limit set by the memory controller.
- Physical installation requires standard 260 pin SO-DIMM hardware whereas desktop DIMM modules are physically incompatible due to length and pin configuration.
- Thermal constraints within the chassis mean that high performance memory modules with thick integrated heat spreaders may interfere with the bottom panel closure.
- Latency performance depends on the CAS latency of the installed kits as the BIOS typically lacks manual timing adjustment features for XMP profiles.
- Accessing the memory banks requires removing the entire lower casing which may involve navigating delicate ribbon cables for the integrated light bar system.
