ASUS ROG G713IE-HX017 RAM upgrade specifications
The ASUS ROG Strix G17 model G713IE-HX017 features DDR4-SDRAM memory upgrade specifications with two SO-DIMM slots supporting maximum capacity of 32 GB RAM. Compatible memory modules operate at 3200 MHz frequency. The laptop accommodates SO-DIMM form factor upgrades, allowing users to expand system memory through available slot configurations. Specifications indicate DDR4 memory compatibility for performance enhancement on the G713IE-HX017 gaming platform.
Memory Upgrade Specifications
| Specification | Value |
|---|---|
| Memory slots | 2x SO-DIMM |
| Form factor | SO-DIMM |
| Memory type | DDR4-SDRAM |
| Frequency | 3200 MHz |
| Maximum RAM | 32 GB |
| Voltage | 1.2V |
| Number of pins | 260-pin |
| Interface | PC4 |
| PC Speed Rating | PC4-3200 (PC4-25600) |
| Bandwidth | 25.6 GB/s |
| Laptop Release date | 28 October 2021 |
Additional Notes
- The ASUS ROG G713IE-HX017 employs a 2-slot SO-DIMM architecture, limiting total capacity expansion to 32 GB regardless of individual module density. This constraint reflects the mobile form factor and cannot be circumvented through additional slots.
- DDR4-3200 memory operates at a fixed speed tier. Compatibility requires exact adherence to this frequency specification; modules rated above or below 3200 MHz may fail to initialize or force automatic downclocking, reducing effective bandwidth by 3.125 percent per 100 MHz deviation.
- SO-DIMM modules demand vertical insertion angles of 30 degrees or steeper during installation. Insufficient clearance above the RAM slots from heatsinks, keyboard frameworks, or adjacent components can physically prevent seating. Pre-upgrade physical inspection of the slot area is necessary for successful installation.
- Populating both SO-DIMM slots with matched-capacity modules enables dual-channel memory architecture, doubling memory bandwidth compared to single-channel configuration. Mismatched capacities or speeds force the system into asymmetric single-channel mode on the smaller or slower module, reducing overall throughput efficiency.
- The 32 GB maximum ceiling means a dual-module upgrade path typically routes through 16 GB modules (2x16 GB configuration). This represents the practical upper limit for warranty-safe DDR4-3200 SO-DIMM availability in the mobile segment.
- Factory memory configuration determines upgrade viability. If the system ships with soldered RAM on the motherboard, available SO-DIMM slots may be fewer than 2, capping actual expandable capacity below the stated 32 GB maximum.
