ASUS ROG GU604VI-N4036W RAM upgrade specifications
The ASUS ROG Zephyrus M16 GU604VI-N4036W features DDR5-SDRAM memory with two SO-DIMM slots supporting maximum capacity of 64 GB. The memory specifications include 4800 MHz frequency operation. Compatible upgrade modules utilize SO-DIMM form factor. The laptop accommodates DDR5 memory upgrades through two dedicated slots, allowing users to expand RAM capacity up to the maximum supported 64 GB specification. DDR5-SDRAM technology provides the memory standard for this model's upgrade compatibility.
Memory Upgrade Specifications
| Specification | Value |
|---|---|
| Memory slots | 2x SO-DIMM |
| Form factor | SO-DIMM |
| Memory type | DDR5-SDRAM |
| Frequency | 4800 MHz |
| Maximum RAM | 64 GB |
| Voltage | 1.1V |
| Number of pins | 262-pin |
| Interface | PC5 |
| PC Speed Rating | PC5-4800 (PC5-38400) |
| Bandwidth | 38.4 GB/s |
| Laptop Release date | 18 April 2023 |
Additional Notes
- The ASUS ROG GU604VI-N4036W implements a 2-slot SO-DIMM configuration, meaning RAM upgrades require removal of existing modules rather than population of additional slots, necessitating purchase of matched pairs for capacity expansion.
- DDR5-4800 memory operates at significantly higher latency cycles compared to DDR4 equivalents, creating potential performance variance if mixing modules from different manufacturers or production batches within the 64 GB ceiling.
- The 64 GB maximum capacity constraint is determined by SO-DIMM physical form factor limitations, not chipset architecture, meaning future DDR5 density improvements will not enable exceeding this ceiling without motherboard redesign.
- SO-DIMM modules generate higher power density per square inch than standard UDIMM counterparts, requiring verification that existing thermal management solutions maintain acceptable junction temperatures when populated with high-capacity modules rated for 4800 MHz operation.
- Upgrading from stock configuration to the 64 GB maximum requires purchasing 2x32 GB modules, a cost structure that may exceed incremental upgrade scenarios and should be evaluated against warranty coverage for third-party memory components in gaming workstations.
- DDR5-4800 frequency specification indicates the system does not support JEDEC DDR5-5600 or higher speeds, confining upgrade options to modules explicitly rated for 4800 MHz to avoid stability degradation or automatic downclocking.
