ASUS TUF Dash TUF517ZM-HN193W RAM upgrade specifications
ASUS TUF Dash F15 series model TUF517ZM-HN193W features two SO-DIMM memory slots supporting DDR5-SDRAM upgrade specifications. Maximum RAM capacity reaches 32 GB per slot for total expandable memory of 64 GB. Compatible memory operates at 4800 MHz frequency. RAM upgrade specifications enable users to enhance laptop performance through compatible DDR5 modules installed in available slots.
Memory Upgrade Specifications
| Specification | Value |
|---|---|
| Memory slots | 2x SO-DIMM |
| Form factor | SO-DIMM |
| Memory type | DDR5-SDRAM |
| Frequency | 4800 MHz |
| Maximum RAM | 32 GB |
| Voltage | 1.1V |
| Number of pins | 262-pin |
| Interface | PC5 |
| PC Speed Rating | PC5-4800 (PC5-38400) |
| Bandwidth | 38.4 GB/s |
Additional Notes
- The dual channel architecture requires symmetrical module pairs to achieve peak memory bandwidth and prevent processor data starvation during heavy rendering or gaming.
- Reliance on a 4800 MHz frequency indicates the motherboard chipset lacks support for XMP or higher speed profiles common in enthusiast grade DDR5 modules.
- Accessing the 2 SO-DIMM slots inside the ASUS TUF Dash TUF517ZM-HN193W requires the removal of the bottom chassis panel which may involve proprietary screws or plastic clips susceptible to fatigue.
- Installation of aftermarket memory exceeding the specified 32 GB threshold results in a failure to post or unstable system behavior due to firmware level addressable space limitations.
- Standard voltage DDR5 modules are required as the platform does not provide manual BIOS controls for voltage adjustment or timing latency overrides.
- The internal physical clearance for memory is restricted to standard height SO-DIMM sticks meaning modules with integrated heat spreaders will likely interfere with the chassis closure.
- Upgrading to the maximum capacity necessitates the removal of existing factory modules because the system lacks additional vacant expansion headers.
