ASUS TUF Gaming FA506QR-AZ061T RAM upgrade specifications
ASUS TUF Gaming A15 FA506QR-AZ061T laptop features two SO-DIMM memory slots supporting DDR4-SDRAM upgrade modules. Maximum RAM capacity reaches 32 GB total, with compatible memory operating at 3200 MHz frequency. Specifications indicate two slots available for memory expansion, allowing users to upgrade from factory-installed configuration to supported maximum capacity. DDR4 SO-DIMM modules meeting 3200 MHz specifications are compatible with this gaming laptop model.
Memory Upgrade Specifications
| Specification | Value |
|---|---|
| Memory slots | 2x SO-DIMM |
| Form factor | SO-DIMM |
| Memory type | DDR4-SDRAM |
| Frequency | 3200 MHz |
| Maximum RAM | 32 GB |
| Voltage | 1.2V |
| Number of pins | 260-pin |
| Interface | PC4 |
| PC Speed Rating | PC4-3200 (PC4-25600) |
| Bandwidth | 25.6 GB/s |
| Laptop Release date | 01 August 2021 |
Additional Notes
- The dual channel architecture requires symmetrical module pairs to achieve maximum memory bandwidth for the Ryzen processor in the ASUS TUF Gaming FA506QR-AZ061T.
- The 32 GB threshold indicates a firmware limitation on the density of the memory controller rather than a physical slot restriction.
- Upgrading to modules with higher clock speeds results in automatic downclocking to the 3200 MHz system ceiling to maintain stability.
- Accessing the SO-DIMM slots requires the removal of the bottom chassis plate which may involve different screw lengths and hidden plastic clips.
- The use of integrated graphics alongside a dedicated GPU means a portion of the system RAM is permanently allocated as video memory.
- Latency performance depends on the CAS latency of the replacement sticks as the motherboard lacks XMP profile support for manual timing adjustments.
- Population of both slots is necessary to eliminate single channel bottlenecks during high CPU load scenarios.
