ASUS TUF Gaming FA506QR-HN036T RAM upgrade specifications
ASUS TUF Gaming A15 FA506QR-HN036T RAM upgrade specifications include DDR4-SDRAM memory compatibility with 2x SO-DIMM slots supporting maximum capacity of 32 GB. Compatible memory modules operate at 3200 MHz frequency. Upgrading RAM requires SO-DIMM form factor modules. Specifications indicate supported maximum upgrade capacity for enhanced multitasking performance on the laptop model FA506QR-HN036T.
Memory Upgrade Specifications
| Specification | Value |
|---|---|
| Memory slots | 2x SO-DIMM |
| Form factor | SO-DIMM |
| Memory type | DDR4-SDRAM |
| Frequency | 3200 MHz |
| Maximum RAM | 32 GB |
| Voltage | 1.2V |
| Number of pins | 260-pin |
| Interface | PC4 |
| PC Speed Rating | PC4-3200 (PC4-25600) |
| Bandwidth | 25.6 GB/s |
| Laptop Release date | 04 May 2021 |
Additional Notes
- Dual channel memory architecture requires matching module capacities and timings across both slots to maximize Zen 3 processor throughput and integrated graphics bandwidth.
- The 32 GB ceiling represents the verified firmware threshold for the ASUS TUF Gaming FA506QR-HN036T and dictates that 16 GB is the largest individual module density supported per slot.
- Lack of soldered memory ensures that the entire system memory remains serviceable if a single module fails.
- Utilizing modules with higher frequencies than 3200 MHz results in downlocking to match the internal memory controller limitations of the chipset.
- The physical SO-DIMM interface necessitates the use of unbuffered non-ECC modules to maintain system stability and POST compatibility.
- Total memory replacement is required to reach maximum capacity if both factory slots are occupied by lower density modules.
