ASUS TUF Gaming FA507NUR-LP003 RAM upgrade specifications
The ASUS TUF Gaming A15 FA507NUR-LP003 laptop features two SO-DIMM memory slots supporting DDR5-SDRAM upgrade capacity. The maximum RAM configuration reaches 64 GB total memory. Memory modules operate at 4800 MHz frequency. Compatible upgrades utilize SO-DIMM form factor specifications for DDR5 technology. Existing memory slots allow for modular RAM expansion to achieve maximum supported specifications. The upgrade slots accommodate DDR5-SDRAM modules meeting the 4800 MHz frequency standard for the FA507NUR-LP003 model.
Memory Upgrade Specifications
| Specification | Value |
|---|---|
| Memory slots | 2x SO-DIMM |
| Form factor | SO-DIMM |
| Memory type | DDR5-SDRAM |
| Frequency | 4800 MHz |
| Maximum RAM | 64 GB |
| Voltage | 1.1V |
| Number of pins | 262-pin |
| Interface | PC5 |
| PC Speed Rating | PC5-4800 (PC5-38400) |
| Bandwidth | 38.4 GB/s |
Additional Notes
- The ASUS TUF Gaming FA507NUR-LP003 uses SO-DIMM form factor memory, which is physically smaller than desktop DIMM modules and requires careful insertion at a 45-degree angle followed by downward pressure to seat properly.
- DDR5-SDRAM operating at 4800 MHz delivers approximately 76.8 GB/s memory bandwidth, substantially higher than DDR4 alternatives, but this advantage is only realized when both DIMM slots contain compatible DDR5 modules operating at matched frequencies.
- The 2-slot configuration means maximum capacity is constrained to 64 GB total; upgrading beyond this threshold requires replacing existing modules rather than adding additional ones, since no third or fourth slot exists.
- Installing mismatched frequency ratings across the 2 slots triggers automatic downclocking to the lower frequency specification, reducing memory bandwidth and potentially diminishing gaming frame rates and multitasking responsiveness.
- SO-DIMM memory modules are more prone to unseating due to thermal cycling and vibration in mobile environments compared to desktop counterparts, necessitating periodic reseating verification if system stability degrades after upgrade installation.
- DDR5 memory remains substantially more expensive per gigabyte than DDR4 equivalents, making 64 GB configurations a significant capital investment with limited warranty protection from third-party sellers in secondary markets.
- Warranty coverage typically becomes void if non-authorized service personnel perform the memory upgrade; authorized technicians must handle installation to preserve manufacturer protection and support eligibility.
