ASUS TUF Gaming FA507NV-HQ012W RAM upgrade specifications
The ASUS TUF Gaming A15 FA507NV-HQ012W features DDR5-SDRAM memory configuration with two SO-DIMM slots supporting maximum RAM capacity of 32 GB. Memory upgrade specifications include DDR5 technology operating at 4800 MHz frequency. Compatible memory modules utilize SO-DIMM form factor for this gaming laptop model. Maximum expandable memory reaches 32 GB total across both available slots, enabling performance enhancement through RAM upgrades on the FA507NV-HQ012W platform.
Memory Upgrade Specifications
| Specification | Value |
|---|---|
| Memory slots | 2x SO-DIMM |
| Form factor | SO-DIMM |
| Memory type | DDR5-SDRAM |
| Frequency | 4800 MHz |
| Maximum RAM | 32 GB |
| Voltage | 1.1V |
| Number of pins | 262-pin |
| Interface | PC5 |
| PC Speed Rating | PC5-4800 (PC5-38400) |
| Bandwidth | 38.4 GB/s |
Additional Notes
- The ASUS TUF Gaming FA507NV-HQ012W accepts DDR5 SO-DIMM modules exclusively, which means DDR4 upgrades will not physically insert into the memory slots regardless of adapter attempts.
- Maximum addressable memory of 32 GB represents a 2-slot constraint that prevents expansion beyond this ceiling, even if higher-capacity individual modules become available in future DDR5 generations.
- SO-DIMM form factor indicates this system uses mobile-grade memory architecture, requiring specialized modules distinct from standard desktop DDR5 DIMMs that would be incompatible with the motherboard layout.
- 4800 MHz native frequency establishes the baseline performance tier; modules rated above this speed will downclock to 4800 MHz due to JEDEC specifications, offering no performance advantage from premium higher-frequency variants.
- The 2-slot configuration means both memory channels can be populated simultaneously for dual-channel operation, but only if both slots contain installed modules; single-module installations will forfeit bandwidth benefits associated with multi-channel memory architecture.
- Warranty coverage for third-party memory replacements typically requires exact specification matching; deviations in voltage, timing parameters, or thermal characteristics outside ASUS qualification lists may void memory-related coverage depending on regional warranty terms.
- Latency characteristics of DDR5-4800 modules will fundamentally differ from DDR4 equivalents; direct performance comparisons between previous-generation systems and this platform require consideration of architectural differences beyond raw frequency ratings.
