ASUS TUF Gaming FX506HCB-HN143W-BE RAM upgrade specifications
The ASUS TUF Gaming F15 FX506HCB-HN143W-BE features DDR4-SDRAM memory with two SO-DIMM slots supporting maximum capacity of 32 GB RAM. The laptop specifications include DDR4 memory operating at 3200 MHz frequency. Compatible RAM upgrades must utilize SO-DIMM form factor modules. The upgrade slots accommodate DDR4 memory modules, allowing users to expand existing memory configurations up to the maximum supported capacity of 32 GB total. Memory specifications and compatible upgrade options are available for this TUF Gaming model.
Memory Upgrade Specifications
| Specification | Value |
|---|---|
| Memory slots | 2x SO-DIMM |
| Form factor | SO-DIMM |
| Memory type | DDR4-SDRAM |
| Frequency | 3200 MHz |
| Maximum RAM | 32 GB |
| Voltage | 1.2V |
| Number of pins | 260-pin |
| Interface | PC4 |
| PC Speed Rating | PC4-3200 (PC4-25600) |
| Bandwidth | 25.6 GB/s |
| Laptop Release date | 07 October 2021 |
Additional Notes
- The presence of 2 dedicated SO-DIMM slots in the ASUS TUF Gaming FX506HCB-HN143W-BE enables a symmetrical dual-channel memory configuration for improved memory bandwidth and reduced processing latencies.
- Upgrading to the maximum 32 GB capacity requires a matched pair of 16 GB modules to maintain optimal stability and prevent system throttling under heavy multitasking or gaming loads.
- Modules with higher frequencies will automatically downclock to 3200 MHz due to firmware limitations of the integrated memory controller.
- The physical installation process necessitates a grounded workspace to prevent electrostatic discharge from damaging the sensitive internal circuitry surrounding the open memory banks.
- Populating both slots with identical memory ranks and timings ensures the hardware maintains consistent data transfer rates across the entire addressable space.
- Thermal constraints within the compact chassis suggest avoiding memory modules with bulky heat spreaders that might interfere with the bottom panel closure.
- Standard low-voltage DDR4 modules are required to ensure power delivery remains within the localized voltage regulator specifications for the motherboard.
