ASUS TUF Gaming FX506HE-HN008T RAM upgrade specifications

ASUS FX506HE-HN008T ASUS FX506HE-HN008T ASUS FX506HE-HN008T ASUS FX506HE-HN008T ASUS FX506HE-HN008T

ASUS TUF Gaming F15 FX506HE-HN008T features DDR4-SDRAM memory upgradeable to maximum capacity of 32 GB. Laptop specifications include 2x SO-DIMM memory slots supporting DDR4 modules at 3200 MHz frequency. Compatible RAM upgrade options utilize SO-DIMM form factor. Memory specifications indicate maximum supported capacity of 32 GB total across both available slots.

Memory Upgrade Specifications

SpecificationValue
Memory slots2x SO-DIMM
Form factorSO-DIMM
Memory typeDDR4-SDRAM
Frequency3200 MHz
Maximum RAM32 GB
Voltage1.2V
Number of pins260-pin
InterfacePC4
PC Speed RatingPC4-3200 (PC4-25600)
Bandwidth25.6 GB/s
Laptop Release date10 December 2021

Additional Notes

  • The dual slot configuration requires identical module pairs to activate dual channel mode for optimized memory bandwidth.
  • The ASUS TUF Gaming FX506HE-HN008T motherboard architecture limits the addressable memory space to 32 GB regardless of higher capacity modules being physically compatible.
  • Installing modules with speeds exceeding 3200 MHz will result in automatic downclocking to match the system bus limitations.
  • Both memory banks are accessible via the bottom panel which facilitates hardware maintenance without disturbing the primary cooling assembly.
  • Existing factory memory must be removed to reach the maximum capacity since no portion of the RAM is soldered to the printed circuit board.
  • The SO-DIMM form factor necessitates 260-pin modules designed specifically for mobile chipsets rather than desktop components.
  • Mixing modules with different CAS latencies will force the system to operate at the timings of the slowest installed stick.
