ASUS TUF Gaming FX506HE-HN011 RAM upgrade specifications

ASUS FX506HE-HN011 ASUS FX506HE-HN011 ASUS FX506HE-HN011 ASUS FX506HE-HN011 ASUS FX506HE-HN011

ASUS TUF Gaming F15 series FX506HE-HN011 laptop supports DDR4-SDRAM memory upgrades. The system features 2x SO-DIMM slots for RAM expansion, compatible with DDR4-3200 MHz modules. Maximum memory capacity reaches 32 GB total. Current specifications allow memory upgrades to enhance multitasking performance and system responsiveness on this gaming-oriented notebook configuration.

Memory Upgrade Specifications

SpecificationValue
Memory slots2x SO-DIMM
Form factorSO-DIMM
Memory typeDDR4-SDRAM
Frequency3200 MHz
Maximum RAM32 GB
Voltage1.2V
Number of pins260-pin
InterfacePC4
PC Speed RatingPC4-3200 (PC4-25600)
Bandwidth25.6 GB/s
Laptop Release date26 January 2022

Additional Notes

  • Dual channel architecture requires matching memory modules in both slots to provide maximum memory bandwidth for the processor and discrete graphics card.
  • The 32 GB ceiling necessitates the removal of existing factory modules to reach the maximum capacity because there are no additional vacant expansion slots.
  • The ASUS TUF Gaming FX506HE-HN011 relies on the integrated memory controller for stability so installing modules with higher frequencies will result in automatic downclocking to the 3200 MHz system limit.
  • Using high density 16 GB SO-DIMM sticks allows for the peak supported configuration while maintaining a low thermal profile within the compact chassis.
  • Upgrading memory requires the removal of the bottom panel which exposes internal components to potential electrostatic discharge and requires specialized tools for the captive screw mechanism.
  • Latencies and timings must match between both slots to prevent system instability or failure to boot during high load gaming scenarios.
