ASUS TUF Gaming FX507ZE-HN061W RAM upgrade specifications
ASUS TUF Gaming F15 FX507ZE-HN061W laptop features two SO-DIMM slots supporting DDR5-SDRAM memory upgrades. Compatible memory modules operate at 4800 MHz frequency, with maximum capacity of 32 GB total RAM. Upgrade specifications include dual slot configuration for memory expansion, enabling users to increase system memory beyond factory configuration using DDR5 SO-DIMM modules compatible with FX507ZE-HN061W specifications.
Memory Upgrade Specifications
| Specification | Value |
|---|---|
| Memory slots | 2x SO-DIMM |
| Form factor | SO-DIMM |
| Memory type | DDR5-SDRAM |
| Frequency | 4800 MHz |
| Maximum RAM | 32 GB |
| Voltage | 1.1V |
| Number of pins | 262-pin |
| Interface | PC5 |
| PC Speed Rating | PC5-4800 (PC5-38400) |
| Bandwidth | 38.4 GB/s |
| Laptop Release date | 21 January 2022 |
Additional Notes
- The ASUS TUF Gaming FX507ZE-HN061W accommodates DDR5 memory exclusively, which means any DDR4 modules will be physically incompatible and non-functional regardless of slot availability.
- Dual SO-DIMM slots impose a rigid pairing requirement: both modules must match in capacity and timing specifications to avoid BIOS stability issues and performance degradation from asymmetric channel operation.
- The 32 GB capacity ceiling represents the absolute maximum addressable memory, achieved only through 2x 16 GB modules; single-stick configurations will leave one slot unfilled and forfeit dual-channel bandwidth benefits.
- 4800 MHz represents the JEDEC specification floor for DDR5, not an overclocking profile; modules rated above this frequency will downclock to 4800 MHz by default unless the BIOS explicitly supports higher JEDEC speeds.
- SO-DIMM form factor restricts upgrades to laptop-specific modules; desktop DDR5 UDIMM sticks are physically longer and will not seat in the available slots.
- Warranty coverage remains intact when upgrading with non-OEM memory, provided installation adheres to standard static handling protocols and no physical damage occurs during the process.
- A single 16 GB SO-DIMM module upgrade will operate in single-channel mode, reducing effective bandwidth to approximately 50 percent compared to a matching 2x 8 GB dual-channel configuration at identical frequency.
- Memory pressure from gaming workloads and simultaneous background processes may require the full 32 GB allocation to prevent page file thrashing on the storage drive, which dramatically reduces responsiveness.
