ASUS TUF Gaming FX707VV-HX145W-BE RAM upgrade specifications
The ASUS TUF Gaming FX707VV-HX145W-BE laptop features DDR5-SDRAM memory upgrade specifications with 2x SO-DIMM slots. Maximum compatible RAM capacity reaches 32 GB total. Memory operates at 4800 MHz frequency. Upgrade modules must utilize SO-DIMM form factor for compatibility with the F17 series model. Current specifications support standard DDR5 memory configurations for enhanced multitasking and performance capabilities.
Memory Upgrade Specifications
| Specification | Value |
|---|---|
| Memory slots | 2x SO-DIMM |
| Form factor | SO-DIMM |
| Memory type | DDR5-SDRAM |
| Frequency | 4800 MHz |
| Maximum RAM | 32 GB |
| Voltage | 1.1V |
| Number of pins | 262-pin |
| Interface | PC5 |
| PC Speed Rating | PC5-4800 (PC5-38400) |
| Bandwidth | 38.4 GB/s |
Additional Notes
- The presence of 2 physical SO-DIMM slots implies that the factory memory is not soldered to the motherboard, allowing for the complete replacement of both modules if necessary.
- Operating the ASUS TUF Gaming FX707VV-HX145W-BE at the maximum supported 32 GB configuration requires two 16 GB modules to enable dual-channel bandwidth, which is essential for alleviating CPU bottlenecks during high-frame-rate gaming.
- Installing memory with frequencies higher than 4800 MHz will result in downclocking to the system limit, as the chipset architecture enforces a hardware cap on data transfer rates.
- Internal component access for memory installation involves removing the bottom chassis panel, which requires caution to avoid damaging the plastic retaining clips or static-sensitive traces near the slots.
- Latency performance depends on matching the CAS latency values of both modules, as the system will default to the timings of the slowest installed stick to maintain stability.
- Upgrading to the 32 GB threshold provides sufficient overhead for heavy multitasking and background recording without triggering page file usage on the primary storage drive.
