DELL Latitude 5431 RAM upgrade specifications

Dell Latitude 5431 laptop supports DDR5-SDRAM memory upgrades with 2x SO-DIMM slots. Maximum RAM capacity reaches 64 GB. Compatible memory modules operate at 4800 MHz frequency. SO-DIMM form factor specifications enable memory expansion for enhanced system performance. Upgrade options allow users to configure memory to match operational requirements within the maximum capacity specifications.

Additional Notes

• Dual channel architecture requires matching module capacities in both slots to provide maximum memory bandwidth for the DELL Latitude 5431 integrated graphics processor.
• The 64 GB threshold indicates a 32 GB per slot limitation which prevents the use of high density 48 GB modules developed after the initial hardware release.
• Installation of memory modules with frequencies higher than 4800 MHz results in automatic downclocking to the system bus limit due to chipset firmware restrictions.
• Standard voltage DDR5 modules are required because the motherboard lacks support for older DDR4 or LPDDR low power soldered standards.
• Total physical memory replacement is necessary for upgrades because the absence of soldered RAM means no base memory remains if both SO DIMM slots are occupied.
• Removal of the base cover to access the memory slots involves captive screws and plastic clips that require non marring tools to maintain chassis integrity and warranty compliance.
• Latencies are determined by the slowest installed module if 2 different brands or timings are mixed within the 2 slots.
