MSI Bravo 17 A4DDR-026XFR RAM upgrade specifications

MSI 17 A4DDR-026XFR MSI 17 A4DDR-026XFR MSI 17 A4DDR-026XFR MSI 17 A4DDR-026XFR MSI 17 A4DDR-026XFR

MSI Bravo 17 A4DDR-026XFR laptop features DDR4-SDRAM memory upgrade capacity. The system contains 2x SO-DIMM slots for RAM expansion, supporting maximum memory configuration of 64 GB. Compatible DDR4 modules operate at 3200 MHz frequency. Specifications indicate SO-DIMM form factor for memory modules. Upgrade options allow users to expand existing memory capacity by utilizing available slots. Maximum RAM installation reaches 64 GB total across both memory slots.

Memory Upgrade Specifications

SpecificationValue
Memory slots2x SO-DIMM
Form factorSO-DIMM
Memory typeDDR4-SDRAM
Frequency3200 MHz
Maximum RAM64 GB
Voltage1.2V
Number of pins260-pin
InterfacePC4
PC Speed RatingPC4-3200 (PC4-25600)
Bandwidth25.6 GB/s
Laptop Release date01 May 2020

Additional Notes

  • The MSI Bravo 17 A4DDR-026XFR supports dual-channel memory architecture, enabling theoretical bandwidth up to 51.2 GB/s when both slots are populated with matching modules.
  • DDR4-3200 represents the maximum officially validated speed, though the system may accept higher frequency modules by downclocking them to this baseline.
  • The 64 GB ceiling requires installation of 2x32 GB modules, which must use dual-rank architecture typically found in higher-density SO-DIMM configurations.
  • Mixing modules with different speeds will force all installed memory to operate at the frequency of the slowest module.
  • SO-DIMM modules measure 67.6mm in length compared to standard DIMM, making desktop memory physically incompatible with this form factor.
  • Accessing both memory slots typically requires removal of the bottom panel, potentially voiding manufacturer seals depending on regional warranty terms.
  • Single-channel operation with only one slot populated reduces memory bandwidth by approximately 50 percent, creating performance bottlenecks in bandwidth-sensitive applications.
  • Non-matching capacity configurations remain functional but disable dual-channel mode for the excess capacity beyond the smaller module size.
  • DDR4 voltage operates at 1.2V standard, with some modules requiring XMP profiles that this platform may not support in a laptop implementation.
  • The maximum 64 GB configuration exceeds the requirements of most current applications but provides headroom for virtual machines, large dataset processing, and content creation workflows.
