MSI Gaming GF63 9SC-045NL Thin RAM upgrade specifications

MSI GF63 9SC-045NL Thin MSI GF63 9SC-045NL Thin MSI GF63 9SC-045NL Thin MSI GF63 9SC-045NL Thin MSI GF63 9SC-045NL Thin

The MSI GF63 9SC-045NL Thin gaming laptop features DDR4-SDRAM memory upgrade capabilities. The system contains 2x SO-DIMM slots supporting a maximum RAM capacity of 64 GB. Memory specifications include DDR4 compatibility at 2666 MHz frequency. Upgrade options accommodate SO-DIMM form factor modules, enabling users to expand memory beyond factory configurations. Compatible RAM modules must adhere to DDR4-SDRAM standards and operate at specified frequencies for optimal performance within the GF series specifications.

Memory Upgrade Specifications

SpecificationValue
Memory slots2x SO-DIMM
Form factorSO-DIMM
Memory typeDDR4-SDRAM
Frequency2666 MHz
Maximum RAM64 GB
Voltage1.2V
Number of pins260-pin
InterfacePC4
PC Speed RatingPC4-2666 (PC4-21328)
Bandwidth21.3 GB/s
Laptop Release date07 April 2019

Additional Notes

  • Dual channel mode requires identical module capacities across both slots to maximize memory controller throughput.
  • Installing memory with frequencies exceeding 2666 MHz results in automatic downclocking to match the system bus limitation.
  • The MSI GF63 9SC-045NL Thin utilizes a shared cooling solution where memory modules lack dedicated heat spreaders, relying on internal chassis airflow for thermal regulation.
  • Population of both SO-DIMM slots to the 64 GB limit necessitates the removal of any factory installed hardware since no additional vacant slots exist.
  • High density 32 GB modules must be unbuffered and non-ECC to maintain boot compatibility with the mobile chipset.
  • Internal component access involves penetrating a factory seal sticker which may impact warranty terms depending on local consumer protection laws.
  • Latencies are determined by the slowest installed module when mixing different brands of memory.
