MSI Gaming KATANA GF76 12UC-274AU RAM upgrade specifications
The MSI KATANA GF76 12UC-274AU gaming laptop features DDR4-SDRAM memory upgrade capabilities with 2x SO-DIMM slots supporting a maximum RAM capacity of 64 GB. The compatible memory modules operate at 3200 MHz frequency with SO-DIMM form factor. Specifications indicate the gaming series GF KATANA model accommodates dual memory modules for system expansion and performance optimization.
Memory Upgrade Specifications
| Specification | Value |
|---|---|
| Memory slots | 2x SO-DIMM |
| Form factor | SO-DIMM |
| Memory type | DDR4-SDRAM |
| Frequency | 3200 MHz |
| Maximum RAM | 64 GB |
| Voltage | 1.2V |
| Number of pins | 260-pin |
| Interface | PC4 |
| PC Speed Rating | PC4-3200 (PC4-25600) |
| Bandwidth | 25.6 GB/s |
| Laptop Release date | 19 December 2022 |
Additional Notes
- Dual channel mode functionality requires installing matching modules in both available slots to maximize memory bandwidth for the MSI KATANA GF76 12UC-274AU processor.
- The hardware architecture supports 32 GB modules per slot to reach the total capacity limit of 64 GB.
- Utilizing memory with timings lower than standard JEDEC profiles may result in automatic downclocking if the BIOS lacks manual XMP adjustment features.
- Upgrading beyond the factory configuration requires removing the bottom chassis panel which may involve piercing a factory seal sticker in certain regions.
- The reliance on DDR4 technology instead of DDR5 indicates a fixed voltage architecture that is incompatible with newer 5600 MHz or higher memory standards.
- Physical clearance within the SO DIMM area restricts the use of memory modules equipped with bulky integrated heat spreaders.
- System stability at the maximum 64 GB capacity depends on the integrated memory controller maintaining 3200 MHz speeds under full load across both ranks.
