MSI Gaming GV62 7RC-224UK RAM upgrade specifications
MSI GV62 7RC-224UK Gaming series laptop features DDR4-SDRAM memory upgrade specifications. The system contains 2x SO-DIMM slots supporting maximum RAM capacity of 32 GB total. Compatible memory operates at 2400 MHz frequency with SO-DIMM form factor. Upgrade specifications enable expansion of existing memory configuration to achieve maximum supported capacity for enhanced multitasking performance.
Memory Upgrade Specifications
| Specification | Value |
|---|---|
| Memory slots | 2x SO-DIMM |
| Form factor | SO-DIMM |
| Memory type | DDR4-SDRAM |
| Frequency | 2400 MHz |
| Maximum RAM | 32 GB |
| Voltage | 1.2V |
| Number of pins | 260-pin |
| Interface | PC4 |
| PC Speed Rating | PC4-2400 (PC4-19200) |
| Bandwidth | 19.2 GB/s |
| Laptop Release date | 25 June 2018 |
Additional Notes
- Dual slot architecture permits the use of dual channel memory mode which significantly increases memory bandwidth compared to single module configurations.
- The 32 GB threshold indicates the motherboard firmware supports high density 16 GB modules per slot despite the older generation chipset.
- Installing memory with frequencies higher than 2400 MHz results in automatic downclocking to match the native system bus speed.
- The MSI GV62 7RC-224UK utilizes the SO-DIMM form factor which excludes the use of standard desktop DIMM modules due to physical pin count and voltage differences.
- A full 32 GB configuration provides sufficient overhead for video editing and heavy multitasking that exceeds standard gaming requirements.
- Accessing the internal slots requires the removal of the entire base panel which involves breaking the factory seal and potentially impacting regional warranty terms.
- Latency performance is optimized by installing two identical modules to avoid timing mismatches between different silicon manufacturers.
